For model S143U -01, Siera; Belgien:
private library

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1946/1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH21 UCH21 UBL21 UY1N
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: S143U -01 - Siera; Belgien
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes
3 Band reception:
  • LW: 708 - 2000 m.
  • BC: 200 - 585 m.
  • SW: 16,5 - 52 m.

Connector for second low impedance loudspeaker.

Tuning scale lightbulbs: 2 x 8095D (19V, 90mA)

There is a model S143U without suffix and a different intermediate frequency.

Attention: chassis connected to the mains !

Mentioned in Technisch- Commercieel - Radio Vademecum Staleman

Model page created by Dirk Bladt. See "Data change" for further contributors.
