S271A-60

S271A-60; Siera; Belgien (ID = 424426) Radio

S271A-60; Siera; Belgien (ID = 424427) Radio

S271A-60; Siera; Belgien (ID = 424424) Radio

S271A-60; Siera; Belgien (ID = 424425) Radio

S271A-60; Siera; Belgien (ID = 424420) Radio

S271A-60; Siera; Belgien (ID = 424421) Radio

S271A-60; Siera; Belgien (ID = 424422) Radio

S271A-60; Siera; Belgien (ID = 424423) Radio

S271A-60; Siera; Belgien (ID = 424428) Radio

S271A-60; Siera; Belgien (ID = 424429) Radio
S271A-60; Siera; Belgien (ID = 1786761) Radio
Use red slider bar for more.
S271A-60; Siera; Belgien (ID = 1786761) Radio
Siera; Belgien: S271A-60 [Radio] ID = 1786761 933x659
Select picture or schematic to display from thumbnails on the right and click for download.
For model S271A-60, Siera; Belgien

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1951 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH42 EAF42 EBC41 EL41 AZ41
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: S271A-60 - Siera; Belgien
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 400 x 265 x 210 mm / 15.7 x 10.4 x 8.3 inch
Notes Dial lamp: 8045D (6,3V/0,3A)
Net weight (2.2 lb = 1 kg) 6.6 kg / 14 lb 8.6 oz (14.537 lb)
Source of data -- Collector info (Sammler)

Model page created by Georges Van Campenhout. See "Data change" for further contributors.



All listed radios etc. from Siera; Belgien
Here you find 435 models, 394 with images and 178 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
