S271A; Siera; Belgien (ID = 268134) Radio
Siera; Belgien: S271A [Radio] ID = 268134 579x375
Select picture or schematic to display from thumbnails on the right and click for download.
For model S271A, Siera; Belgien

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH42 EAF42 EBC41 EL41 AZ41
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch
Power out
from Radiomuseum.org Model: S271A - Siera; Belgien
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 395 x 260 x 180 mm / 15.6 x 10.2 x 7.1 inch
Notes Dial lamp: 8045D (6,3V/0,32A).
Net weight (2.2 lb = 1 kg) 6.6 kg / 14 lb 8.6 oz (14.537 lb)
Price in first year of sale 3'450.00 BFr
Source of data -- Original prospect or advert

Model page created by Hugo Sneyers. See "Data change" for further contributors.



All listed radios etc. from Siera; Belgien
Here you find 435 models, 394 with images and 178 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
