S88A

S88A; Siera; Belgien (ID = 1922200) Radio

S88A; Siera; Belgien (ID = 1922201) Radio

S88A; Siera; Belgien (ID = 1922202) Radio

S88A; Siera; Belgien (ID = 1922203) Radio

S88A; Siera; Belgien (ID = 1922204) Radio
S88A; Siera; Belgien (ID = 1922216) Radio S88A; Siera; Belgien (ID = 2053498) Radio
S88A; Siera; Belgien (ID = 2053501) Radio S88A; Siera; Belgien (ID = 2053502) Radio
S88A; Siera; Belgien (ID = 2053503) Radio S88A; Siera; Belgien (ID = 2053504) Radio
Use red slider bar for more.
S88A; Siera; Belgien (ID = 1922216) Radio
Siera; Belgien: S88A [Radio] ID = 1922216 644x528
Select picture or schematic to display from thumbnails on the right and click for download.
For model S88A, Siera; Belgien:
from Siera memento of tubes and models 1932-1946

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH3 EF9 EBC3 CL4 CY1
Main principle Superheterodyne (common); ZF/IF 454 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: S88A - Siera; Belgien
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 350 x 230 x 180 mm / 13.8 x 9.1 x 7.1 inch
Notes
3 Band reception:
  • BC: 160 - 570 m.
  • SW1: 13,5 - 45 m.
  • SW2: 45 - 160 m.
Tuning scale light bulbs type: 8092D (10V, 200mA).
Loudspeaker Philips type 9648. No connectors for external loudspeaker or pick-up.

This model is comparable with:

Attention: The mains is connected to the chassis.

Net weight (2.2 lb = 1 kg) 5.9 kg / 12 lb 15.9 oz (12.996 lb)
Mentioned in - - Manufacturers Literature (Siera memento of tubes and models 1932-1946)

Model page created by John Koster. See "Data change" for further contributors.



All listed radios etc. from Siera; Belgien
Here you find 434 models, 393 with images and 178 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
