SA43T110A

SA43T110A; Siera; Belgien (ID = 157449) Television

SA43T110A; Siera; Belgien (ID = 157451) Television

SA43T110A; Siera; Belgien (ID = 157452) Television

SA43T110A; Siera; Belgien (ID = 157454) Television

SA43T110A; Siera; Belgien (ID = 157455) Television

SA43T110A; Siera; Belgien (ID = 157457) Television

SA43T110A; Siera; Belgien (ID = 157448) Television
SA43T110A; Siera; Belgien (ID = 157062) Television SA43T110A; Siera; Belgien (ID = 157063) Television
SA43T110A; Siera; Belgien (ID = 157064) Television
Use red slider bar for more.
SA43T110A; Siera; Belgien (ID = 157062) Television
Siera; Belgien: SA43T110A [Television] ID = 157062 880x696
Select picture or schematic to display from thumbnails on the right and click for download.
For model SA43T110A, Siera; Belgien

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1956 Category: Television Receiver (TV) or Monitor
Valves / Tubes 22: PCC84 PCF80 EF80 ECH81 EF80 PABC80 PL82 EF80 EF80 EF80 EF80 PL83 ECC82 EF80 ECL80 ECL80 PL81 PY81 DY86 ECL80 PL82 MW43-69
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: SA43T110A - Siera; Belgien
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 550 x 500 x 560 mm / 21.7 x 19.7 x 22 inch
Notes Wellenbereich: VHF; 4-Normen-Gerät.
Source of data - - Data from my own collection

Model page created by Hugo Sneyers. See "Data change" for further contributors.
