Musette MK-J
Use red slider bar for more.
S.P. Radio A/S;: Musette MK-J [Radio] ID = 600263 933x611
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
Brand
|
Sailor | ||||
|---|---|---|---|---|---|
| Year: 1958 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 5: UCC85 UCH81 UBF89 UCL82 UM35 |
| Main principle | Superheterodyne (common); ZF/IF ? kHz |
|---|---|
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | |
| Power type and voltage | AC/DC-set / 110; 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch |
| Power out | |
| from Radiomuseum.org | Model: Musette MK-J - S.P. Radio A/S; Aalborg |
| Material | Wooden case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 495 x 325 x 250 mm / 19.5 x 12.8 x 9.8 inch |
| Notes | Fischereiband als 4 Wellenbereich, drehbare Ferritantenne |
Model page created by Thorsten Finaske. See "Data change" for further contributors.
