• Country
• Sweden

• Manufacturer / Brand
• SR, Svenska Radioaktiebolaget (SRA, Radiola); Stockholm

• Year
• 1949

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 104065

• • Brand: Radiola

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• MUCH42 or UCH42 MUF41 or UF41 MUBC41 or UBC41 MUL41 or UL41 MUY41 or UY41

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110-120; 127-140; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.5 cm = 4.1 inch

• Power out
• 3 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Radiola Balett 512LV - SR, Svenska Radioaktiebolaget

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 280 x 164 x 133 mm / 11 x 6.5 x 5.2 inch

• Notes
• Output: 3 W at 220 V; 0,6 W at 110 V.

• Net weight (2.2 lb = 1 kg)
• 2.7 kg / 5 lb 15.2 oz (5.947 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Peter Olausson. See "Data change" for further contributors.
