• Year
  • 1960
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 156640

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common); ZF/IF 473/10800 kHz
  • Tuned circuits
  • 8 AM circuit(s)     11 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • 3 Loudspeakers
  • Power out
  • 4 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Juwel 2 Phono 3D [OIRT] - Stern-Radio Rochlitz, VEB, RFT
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 630 x 395 x 285 mm / 24.8 x 15.6 x 11.2 inch
  • Notes
  • Exportversion für CS, UKW OIRT-Band 66...73,5 MHz. 3-D- Umschaltung.

    Mit Abspielgerät "Ziphona A 30" für 17-cm-Platten (Briefkastenschlitz).

  • Net weight (2.2 lb = 1 kg)
  • 19.8 kg / 43 lb 9.8 oz (43.612 lb)
  • Price in first year of sale
  • 2,300.00 CZK
  • Author
  • Model page created by Wolfgang Lill. See "Data change" for further contributors.
