Excellent 6490; Stern-Radio (ID = 1243608) Radio
Stern-Radio: Excellent 6490 [Radio] ID = 1243608 933x356
Select picture or schematic to display from thumbnails on the right and click for download.
For model Excellent 6490, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1973/1974 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: Selen
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Excellent 6490 - Stern-Radio Sonneberg, VEB,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 480 x 115 x 145 mm / 18.9 x 4.5 x 5.7 inch
Notes

Gehäuse Holzfurnier, poliert oder matt. Ferritantenne für MW und KW, KW nur 49-m-Band, Klangtaste.

Fertigung wurde zu Robotron Radeberg verlagert und dort weiter als Excellent 6490 produziert.

Exportmodell mit UKW bis 108 MHz = Excellent 6500.

Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 320.00 DM
Collectors' prices
Mentioned in Die Geschichte der Rundfunkindustrie der DDR Band 2 1968 - 1990
Literature/Schematics (1) - - Manufacturers Literature (Service- DVD vom Funkverlag B. Hein)

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
