Jena 5020C

Jena 5020C; Stern-Radio (ID = 467542) Radio

Jena 5020C; Stern-Radio (ID = 649941) Radio

Jena 5020C; Stern-Radio (ID = 649942) Radio

Jena 5020C; Stern-Radio (ID = 649943) Radio

Jena 5020C; Stern-Radio (ID = 649944) Radio

Jena 5020C; Stern-Radio (ID = 649945) Radio
Use red slider bar for more.
Jena 5020C; Stern-Radio (ID = 467542) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1961 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EBF89 EABC80 EM84 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.8 W (unknown quality)
from Radiomuseum.org Model: Jena 5020C - Stern-Radio Sonneberg, VEB,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 520 x 280 x 225 mm / 20.5 x 11 x 8.9 inch
Notes Der Mittelsuper Jena 5020C hat für MW und LW eine Ferritantenne. Aufgebaut ist das Gerät mit den standardisierten Baugruppen für Mittelsuper der unteren Preisklasse.
Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Price in first year of sale 410.00 DM
Mentioned in Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967
Literature/Schematics (1) Service-DVD Funkverlag B. Hein

Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
