Stern-Radio: Saalburg 5170C [Radio] ID = 2061682 1208x887

Select picture or schematic to display from thumbnails on the right and click for download.

For model Saalburg 5170C, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Country:

Germany

Manufacturer / Brand:

Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Year: 1964

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

7: ECC85 ECH81 EBF89 EABC80 EM84 EL84 EZ80

Main principle

Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz

Tuned circuits

6 AM circuit(s) 10 FM circuit(s)

Wave bands

Broadcast, Long Wave, Short Wave plus FM or UHF.

Details

Power type and voltage

Alternating Current supply (AC) / 110; 127; 220; 240 Volt

Loudspeaker

Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

Power out

3 W (unknown quality)

from Radiomuseum.org

Model: Saalburg 5170C - Stern-Radio Sonneberg, VEB,

Dimensions (WHD)

520 x 280 x 225 mm / 20.5 x 11 x 8.9 inch

Notes

Der Empfänger Saalburg 5170C ist eine Exportversion des Saalburg 5170. Der Empfangsbereich UKW ist bis 104 MHz erweitert und für LW und MW ist eine Ferritantenne eingebaut.

Net weight (2.2 lb = 1 kg)

8.5 kg / 18 lb 11.6 oz (18.722 lb)

Mentioned in

Service-DVD Funkverlag B. Hein

Literature/Schematics (1)

Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967

Literature/Schematics (2)

-- Original-techn. papers.

Documents about this model

Serviceanleitung

5044 KB

Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.
