Weimar 467

Weimar 467; Stern-Radio (ID = 555710) Radio

Weimar 467; Stern-Radio (ID = 555711) Radio

Weimar 467; Stern-Radio (ID = 555712) Radio

Weimar 467; Stern-Radio (ID = 555713) Radio

Weimar 467; Stern-Radio (ID = 841402) Radio
Use red slider bar for more.
Weimar 467; Stern-Radio (ID = 555710) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1961/1962 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EBF89 EABC80 EL84 EZ80
Main principle ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Weimar 467 - Stern-Radio Sonneberg, VEB,
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes Holzgehäuse poliert, getrennte Regler für Höhen und Tiefen
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
External source of data Service CD EAK Köppelsdorf/Stern Radio Sonneberg
Source of data Radiokatalog Band 2, Ernst Erb

Model page created by Karl Günther Goldsteiner. See "Data change" for further contributors.
