• Country
• Germany

• Manufacturer / Brand
• Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...

• Year
• 1965–1967

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 72818

• • alternative name: Fernsehgerätewerk Staßfurt

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• PC88 PCF82 PCF82 PCF82 EF183 EF80 EF80 EF80 PCL84 PABC80 PL84 PL84 ECC82 PL500 PY88 DY86 B59G1

• Number of Transistors

• Semiconductors
• OC824 OC824

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Sibylle 108 - Stern-Radio Staßfurt, VEB, RFT

• Dimensions (WHD)
• 700 x 500 x 410 mm / 27.6 x 19.7 x 16.1 inch

• Notes
• VHF-Bereich, Selengleichrichter.

• External source of data
• Werner Zimmermann

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Andreas Hahn. See "Data change" for further contributors.
