TeKaDe TKD,: W487 [Radio] ID = 54098 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model W487, TeKaDe (TKD), Süddeutsche Telefon-Apparate- Kabel- und Drahtwerke; Nürnberg

Country:  Germany
Manufacturer / Brand:  TeKaDe (TKD), Süddeutsche Telefon-Apparate- Kabel- und Drahtwerke; Nürnberg
alternative name

Felten & Guilleaume || Südd.Telefon-App., Kabel- und Drahtwerke AG || Telade
Brand
KD
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EF89 EM80 EABC80 EL84
schematic requested
Main principle Superheterodyne (common); ZF/IF 472/10700 kHz
Tuned circuits 8 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker 2 Loudspeakers
Power out 6 W (unknown quality)
from Radiomuseum.org Model: W487 - TeKaDe TKD, Süddeutsche
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 670 x 400 x 310 mm / 26.4 x 15.7 x 12.2 inch
Notes

Lautsprecher:  1 x Pdyn, 1 x elektrostatischer LS.

Net weight (2.2 lb = 1 kg) 14 kg / 30 lb 13.4 oz (30.837 lb)
Price in first year of sale 358.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1954/55
