347WL (T347WL)

347WL ; Telefunken (ID = 331324) Radio
347WL ; Telefunken (ID = 359360) Radio 347WL ; Telefunken (ID = 359362) Radio
347WL ; Telefunken (ID = 359361) Radio 347WL ; Telefunken (ID = 444565) Radio
Use red slider bar for more.
347WL ; Telefunken (ID = 359360) Radio
Telefunken: 347WL [Radio] ID = 359360 756x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model 347WL (T347WL), Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1934/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: RENS1214 RENS1214 REN914 RENS1374d RGN1064
Main principle TRF without regeneration; Screengrid 1926-1935
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110 - 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 347WL - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 410 x 440 x 270 mm / 16.1 x 17.3 x 10.6 inch
Notes Identique au modèle Siemens 47aWL, importé et vendu par Siemens Nederland pour le Benelux.
Source of data -- Schematic

Model page created by Alfred Maistriaux. See "Data change" for further contributors.
