FE10St

FE10St; Telefunken (ID = 104379) Television

FE10St; Telefunken (ID = 104380) Television

FE10St; Telefunken (ID = 104381) Television

FE10St; Telefunken (ID = 104382) Television

FE10St; Telefunken (ID = 104383) Television

FE10St; Telefunken (ID = 104384) Television

FE10St; Telefunken (ID = 104385) Television

FE10St; Telefunken (ID = 104386) Television
FE10St; Telefunken (ID = 313341) Television
Use red slider bar for more.
FE10St; Telefunken (ID = 313341) Television
Telefunken: FE10St [Television] ID = 313341 235x361
Select picture or schematic to display from thumbnails on the right and click for download.
For model FE10St, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1954/1955 Category: Television Receiver (TV) or Monitor
Valves / Tubes 18: PCC84 PCF82 EF80 EF80 EF80 EF80 EC92 PL81 PL83 EF80 PABC80 PL82 ECC82 ECC81 PL82 PY83 MW43-64
Main principle Superheterodyne (common); ZF/IF 25750 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: FE10St - Telefunken Deutschland TFK,
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 530 x 915 x 430 mm / 20.9 x 36 x 16.9 inch
Notes 10 VHF-Kanäle + 2 Reserve.
Net weight (2.2 lb = 1 kg) 41 kg / 90 lb 4.9 oz (90.308 lb)
Price in first year of sale 1'098.00 DM
External source of data Erb
Source of data Rundfunk- und Fernseh-Katalog 1954/55
