FE8aT; Telefunken (ID = 659248) Television
Telefunken: FE8aT [Television] ID = 659248 856x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model FE8aT, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1952/1953 Category: Television Receiver (TV) or Monitor
Valves / Tubes 20: EF80 ECC81 EF80 EF80 EF80 EAA91 EF80 PL83 EF80 PABC80 PL82 PCL81 EF80 ECC82 PL82 ECC82 PL81 PY83 DY80 MW36-24
Main principle Superhet with RF-stage; ZF/IF 25275/5500 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: FE8aT - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 600 x 430 x 470 mm / 23.6 x 16.9 x 18.5 inch
Notes

Empfangsbereich: 7 Kanäle im Band III (174 ... 223 MHz).
Intercarrier-Tonteil.

Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Funkschau (5/1953 S.80, Neuvorstellung)

Model page created by Folkert Rothe. See "Data change" for further contributors.
