• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1969

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 301626

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH84 EL504 ECL805 A44-12W or A50-120W or A61-120W

• Number of Transistors
• 16

• Semiconductors
• AF109 AF106 AF106 AF251 AF139 BF198 BF199 BF311 BC237 BF174 BD237 BC237 BC237 BC237 MJE340 ULN2111A BA149 BB102 SFD183 E15C175 AA138 SFD89 BA147 AA132 AA133 V40C2 BY112 BY165 TV20 B30C350 MR31

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: Fernsehchassis 209 mit Tuner MT511 / MT512 - Telefunken Deutschland TFK,

• Shape
• Chassis only or for «building in»

• Notes

• Das Telefunken s/w Chassis 209 wurde 1969/70 unter anderem in den Fernsehempfängern FE170P und FE190P verwendet.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
