• Country
• Italy

• Manufacturer / Brand
• Telefunken Italia, Milano

• Year
• 1961

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 123102

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EF89 EABC80 EL84 UY85

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 120-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Fonomignon R277 - Telefunken Italia, Milano

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 380 x 310 x 250 mm / 15 x 12.2 x 9.8 inch

• Notes
• Gamme d'onda: medie, FM, TV. Giradischi 16-33-45-78 giri.
  Wave bands: BC, FM, audio-TV. Record player: 16, 33, 45, 78 RPM.

• Source of data
• Guida Pratica Antique Radio IV (2001)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
