Gavotte 1063; Telefunken (ID = 2302956) Radio
Telefunken: Gavotte 1063 [Radio] ID = 2302956 1400x921
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gavotte 1063, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1959/1960 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM84 EL84
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Gavotte 1063 - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 460 x 300 x 200 mm / 18.1 x 11.8 x 7.9 inch
Net weight (2.2 lb = 1 kg) 8.2 kg / 18 lb 1 oz (18.062 lb)
Price in first year of sale 259.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1959/60


All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Here you find 3461 models, 3031 with images and 2007 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Telefunken: Gavotte 1063
Threads: 1 | Posts: 1
Hits: 3043     Replies: 0
telefunken: 1063; Gavotte
Kurt Jeranko
07.Feb.07
  1

Ist jemandem bekannt, warum das Nachfolgemodell des Gavotte 9 die Typenbezeichnung

Gavotte 1063 bekam? Was bedeutet die Zahl 1063?



MfG Kurt Jeranko
