For model Jubilate de Luxe 5261W, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1961/1962 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM84 EL95
schematic requested
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Jubilate de Luxe 5261W - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 390 x 220 x 185 mm / 15.4 x 8.7 x 7.3 inch
Notes Telefunken Superheterodyne Jubilate de Luxe 5261 W;
US export version, english labeled, FM up to 108 MHz, DIN terminals for phono, tape and ext. speaker, tuning indicator tube, made in Germany.
