For model Kid II R542, Telefunken Italia, Milano

Country:  Italy
Manufacturer / Brand:  Telefunken Italia, Milano
Year: 1965 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EL84 UY85
Main principle Super-Heterodyne (Super in general)
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 125; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Kid II R542 - Telefunken Italia, Milano
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 370 x 145 x 175 mm / 14.6 x 5.7 x 6.9 inch
Notes

controllo volume - commutatore AM/FM - spia accensione - antenna in ferrite interna per AM - prese per antenna esterna FM 75/75/300 Ω

Net weight (2.2 lb = 1 kg) 3.7 kg / 8 lb 2.4 oz (8.15 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
