Magnetophon automatic ; Telefunken (ID = 753170) R-Player
Telefunken: Magnetophon automatic [R-Player] ID = 753170 584x650
Select picture or schematic to display from thumbnails on the right and click for download.
For model Magnetophon automatic, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Q: Telefunken Service

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1962–1964 Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: EF86 EF83 ECC83 EM84 EL95
Semiconductors (the count is only for transistors) E30C5 E30C5 B250C75
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Magnetophon automatic - Telefunken Deutschland TFK,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 320 x 160 x 310 mm / 12.6 x 6.3 x 12.2 inch
Notes Zweispur; 9,5 cm/s. Spulen-Ø 15 cm.
In Österreich für 4150,- ATS.
Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
Price in first year of sale 464.00 DM
External source of data Erb
Source of data Handbuch VDRG 1963/1964
Mentioned in Funk-Technik (FT) (14/1962, S. 471 - 473 / Ausführlicher Bericht, Daten, Schema)
