For model Mignonette MF R171, Telefunken Italia, Milano

Country:  Italy
Manufacturer / Brand:  Telefunken Italia, Milano
Year: 1955 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 UCH81 UF89 UABC80 DM70 EL84 UY85
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 120; 140; 160; 180; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Mignonette MF R171 - Telefunken Italia, Milano
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 300 x 210 x 180 mm / 11.8 x 8.3 x 7.1 inch
Notes Altoparlante ellittico 9 x 14 cm.
Net weight (2.2 lb = 1 kg) 3.4 kg / 7 lb 7.8 oz (7.489 lb)
Literature/Schematics (1) -- Schematic

Model page created by Enrico Puccini. See "Data change" for further contributors.
