Schönbrunn III (3)

Telefunken; Wien

  • Year
  • 1970
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 129666

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 11
  • Number of Transistors
  • 7
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Schönbrunn III - Telefunken; Wien
  • Shape
  • Tablemodel with Push Buttons.
  • Notes
  • Chassis ident mit Kapsch Viennastar 1025.
    Empfangsbereich: VHF/UHF.
    2 Ausführungen mit 50cm- oder 61cm Bildröhre.
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Wolfgang Bauer. See "Data change" for further contributors.
