Wien 2183 mattiert
Use red slider bar for more.
Telefunken: Wien 2183 [Radio] ID = 839942 800x487
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1960–1962 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 8: ECC85 ECH81 EBF89 ECC83 EM84 EBC91 EL84 ECL86 |
|---|
| Main principle | Superheterodyne (common) |
|---|---|
| Tuned circuits | 6 AM circuit(s) 10 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | Changer (Record changer); Radio Control (+Remote Wire etc) |
| Power type and voltage | Alternating Current supply (AC) / 110; 125; 220; 240 Volt |
| Loudspeaker | 3 Loudspeakers |
| Power out | |
| from Radiomuseum.org | Model: Wien 2183 [mattiert] - Telefunken Deutschland TFK, |
| Material | Wooden case |
| Shape | Console with Push Buttons. |
| Dimensions (WHD) | 1100 x 800 x 420 mm / 43.3 x 31.5 x 16.5 inch |
| Notes | Stereo-NF-Verstärker mit 2 Endstufen je 4 W; Balance-Fernregler (+ 8,50 DM). Phono-Chassis = k. A. |
| Net weight (2.2 lb = 1 kg) | 37 kg / 81 lb 8 oz (81.498 lb) |
| Price in first year of sale | 771.00 DM |
| External source of data | Erb |
| Source of data | HdB d.Rdf-& Ferns-GrH 1961/62 |
