Wiking 125WLK (T125WLK)

Wiking 125WLK ; Telefunken (ID = 1973475) Radio

Wiking 125WLK ; Telefunken (ID = 1973477) Radio

Wiking 125WLK ; Telefunken (ID = 1973472) Radio

Wiking 125WLK ; Telefunken (ID = 1973473) Radio

Wiking 125WLK ; Telefunken (ID = 7549) Radio

Wiking 125WLK ; Telefunken (ID = 1973480) Radio

Wiking 125WLK ; Telefunken (ID = 1973483) Radio

Wiking 125WLK ; Telefunken (ID = 201984) Radio

Wiking 125WLK ; Telefunken (ID = 232390) Radio

Wiking 125WLK ; Telefunken (ID = 243597) Radio
Wiking 125WLK ; Telefunken (ID = 1783878) Radio Wiking 125WLK ; Telefunken (ID = 394249) Radio
Wiking 125WLK ; Telefunken (ID = 1147267) Radio Wiking 125WLK ; Telefunken (ID = 1709142) Radio
Wiking 125WLK ; Telefunken (ID = 3265) Radio Wiking 125WLK ; Telefunken (ID = 30699) Radio
Wiking 125WLK ; Telefunken (ID = 65128) Radio Wiking 125WLK ; Telefunken (ID = 83238) Radio
Wiking 125WLK ; Telefunken (ID = 179849) Radio Wiking 125WLK ; Telefunken (ID = 279847) Radio
Use red slider bar for more.
Wiking 125WLK ; Telefunken (ID = 1783878) Radio
Telefunken: Wiking 125WLK [Radio] ID = 1783878 933x1117
Select picture or schematic to display from thumbnails on the right and click for download.
For model Wiking 125WLK (T125WLK), Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1933–1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: REN914 RENS1374d RGN564
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Wiking 125WLK - Telefunken Deutschland TFK,
Material Bakelite case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 304 x 357 x 180 mm / 12 x 14.1 x 7.1 inch
Notes

Parallelgerät zum Siemens 25WLK.
Parallelgerät zum AEG Geadux 112WLK.

Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Price in first year of sale 153.00 RM !
Collectors' prices
Source of data Radio-Zentrale Prohaska 1933/34 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange + Schenk
Mentioned in Radio-Katalog Fricke 1934/35
Literature/Schematics (1) Radio Schakelingen (J.G.R. van Dijck)


All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Here you find 3381 models, 2938 with images and 1936 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.







Forum contributions about this model
Telefunken: Wiking 125WLK
Threads: 1 | Posts: 1
Hits: 2073     Replies: 0
Telefunken 125 WLK
Eilert Menke
04.Apr.03
  1 Suche hierfür originalen Hauptabstimmknopf sowie den Papp-Anhänger (wurde zu Werbezwecken mit Bindfaden an Lautsprecherstrebe befestigt) mit Wikingerschiff.
