• Year
  • 1958
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 109209

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 483 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16.5 cm = 6.5 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Tesla 58A - Radioindustrija Nikola Tesla;
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 600 x 365 x 245 mm / 23.6 x 14.4 x 9.6 inch
  • Notes
  • Dieses Modell wird auch alternativ mit EM4 statt EM80 gefertigt.

  • Net weight (2.2 lb = 1 kg)
  • 10.4 kg / 22 lb 14.5 oz (22.907 lb)
  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
