Tonperle W299

Tonperle W299; Tonfunk GmbH; (ID = 767954) Radio Tonperle W299; Tonfunk GmbH; (ID = 767958) Radio
Tonperle W299; Tonfunk GmbH; (ID = 767957) Radio Tonperle W299; Tonfunk GmbH; (ID = 767955) Radio
Tonperle W299; Tonfunk GmbH; (ID = 767959) Radio
Use red slider bar for more.
Tonperle W299; Tonfunk GmbH; (ID = 767954) Radio
Tonfunk GmbH;: Tonperle W299 [Radio] ID = 767954 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tonperle W299, Tonfunk GmbH; Karlsruhe

Country:  Germany
Manufacturer / Brand:  Tonfunk GmbH; Karlsruhe
Year: 1956 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM80 EL84
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker 3 Loudspeakers / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: Tonperle W299 - Tonfunk GmbH; Karlsruhe
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 570 x 350 x 220 mm / 22.4 x 13.8 x 8.7 inch
Notes Mit Tonregister, Drehbare Ferritantenne
Net weight (2.2 lb = 1 kg) 9.9 kg / 21 lb 12.9 oz (21.806 lb)

Model page created by Robert Forchert-Mühlbachler. See "Data change" for further contributors.



All listed radios etc. from Tonfunk GmbH; Karlsruhe
Here you find 560 models, 311 with images and 233 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
