• Year
  • 1959–1962
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 22922

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 150; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 2.5 W (unknown quality)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: 502 - Uher Werke; München
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 310 x 150 x 265 mm / 12.2 x 5.9 x 10.4 inch
  • Notes
  • Zweispur; 4,75/9,5 cm/s. Spulen-Ø 13 cm.
  • Net weight (2.2 lb = 1 kg)
  • 6.4 kg / 14 lb 1.6 oz (14.097 lb)
  • Price in first year of sale
  • 423.00 DM
  • External source of data
  • Erb
