Report-L 4000 1966

Uher Werke; München

Data

Forum

Pictures

Collections

Country
Germany

Manufacturer / Brand
Uher Werke; München

Year
1966–1972

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
26797

Schematics

Report-L 4000; Uher Werke; München (ID = 75929) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 75932) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 75935) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 80898) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 80899) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 80900) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 150905) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 150906) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151246) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151247) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151248) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151249) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151250) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151251) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151252) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151253) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151254) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151255) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151256) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151257) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151258) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151259) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151260) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151261) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151262) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151263) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151264) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151265) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 151268) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 2657536) R-Player — Uher Werke; München Report-L 4000 (3)

Report-L 4000; Uher Werke; München (ID = 2375216) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 2375215) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 151406) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 151407) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 151409) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 32505) R-Player — Uher Werke; München Report-L 4000 (2)
Ursprung - Freigabe: Karl Ziegler (A)

Report-L 4000; Uher Werke; München (ID = 151408) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 319935) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 592998) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 592999) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 593000) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 593001) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 593002) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 593003) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 800089) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 994431) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 994432) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 994987) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1152027) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1152028) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1152029) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1152030) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1184136) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1184137) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1304659) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1469538) R-Player — Uher Werke; München Report-L 4000 (1)
Uher 4000L Reporter - In Great condition

Report-L 4000; Uher Werke; München (ID = 1469539) R-Player — Uher Werke; München Report-L 4000 (1)
Uher 4000 L Reporter

Report-L 4000; Uher Werke; München (ID = 1469540) R-Player — Uher Werke; München Report-L 4000 (1)

Report-L 4000; Uher Werke; München (ID = 1469541) R-Player — Uher Werke; München Report-L 4000 (1)
Uher 4000 L Reporter with Batteries

Report-L 4000; Uher Werke; München (ID = 1469542) R-Player — Uher Werke; München Report-L 4000 (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
17

Semiconductors
OC305 AC151 AC153 AC176 BCY51 BFY39 AA116 ZG3,9 ZL7

Main principle
Audio-Amplification

Wave bands
- without

Details
Tape Recorder

Power type and voltage
Storage and/or dry batteries / 5 × 1,5; 6 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

Power out
1 W (unknown quality)

Material
Metal case

from Radiomuseum.org
Model: Report-L 4000 [1966] - Uher Werke; München

Shape
Portable set > 8 inch (also usable without mains)

Dimensions (WHD)
270 x 85 x 215 mm / 10.6 x 3.3 x 8.5 inch

Notes
Halbleiterliste: pro Typ nur einmal;
Transistoren: 6× OC305, 3× AC151, 4× AC153, AC176, BCY51, 2× BFY39; Dioden: 3× AA116, ZG3.9, ZL7.
Zweispur-Mono;
Bandgeschwindigkeiten: 2,4/4,75/9,5/19 cm/s; Spulen-Ø 13 cm.
Stromversorgung auch durch Dryfit-Akku, einschiebbarem Netzgerät oder Autobatterie (6 V, 12 V, 24 V).
Preis zuzüglich 10,- DM Gema-Gebühr.

Net weight (2.2 lb = 1 kg)
3 kg / 6 lb 9.7 oz (6.608 lb)

Price in first year of sale
579.00 DM

External source of data
erb

Source of data
Handbuch VDRG 1966/1967 / Radiokatalog Band 2, Ernst Erb

Mentioned in
Handbuch VDRG 1970/1971

Other Models
