Coronation Twin Deluxe R906

Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 1621992) Radio

Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 1622738) Radio

Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 1622739) Radio

Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 1622740) Radio

Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 1622741) Radio
Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 59142) Radio Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 167074) Radio
Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 167076) Radio Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 178606) Radio
Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 354458) Radio Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 454583) Radio
Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 670644) Radio Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 670645) Radio
Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 670646) Radio Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 670652) Radio
Use red slider bar for more.
Coronation Twin Deluxe R906; Ultra Electric Ltd.; (ID = 59142) Radio
Ultra Electric Ltd.;: Coronation Twin Deluxe R906 [Radio] ID = 59142 517x405
Select picture or schematic to display from thumbnails on the right and click for download.
For model Coronation Twin Deluxe R906, Ultra Electric Ltd.; London

Country:  Great Britain (UK)
Manufacturer / Brand:  Ultra Electric Ltd.; London
alternative name

Ultra Radio and Television
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1C2 1F3 1FD9 1P11 or 3V4
Semiconductors (the count is only for transistors) Metal-rectifier
Main principle Superheterodyne (common); ZF/IF 471 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Line / Batteries (any type) / 200-250 / 7.5 & 85 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: Coronation Twin Deluxe R906 - Ultra Electric Ltd.; London
Material Leather / canvas / plastic - over other material
Dimensions (WHD) 305 x 216 x 165 mm / 12 x 8.5 x 6.5 inch
Notes

NOTE RE. SCHEMATICS
V2 voltage is shown incorrectly it should be 85v not 8.5v

De-luxe version of model R786, housed in a simulated crocodile or snake skin covered case with sliding front doors. It is not clear whether J.Hill refers to the model number R786 only or to its name "Coronation Twin".

More than one colour-way. Cream or dark brown.

If two plugs for  batteries:
HT 85V = Ever Ready B129, LT 7.5V = Ever Ready AD39

If single plug for batteries:

Ever Ready B127 85V + 7.5V combo pack

The two alternates are about the same volume. Both are used on various "Twin" models.



(Coffret forme mallette, en bois gainé imitation reptile - cadran pouvant être masqué par caches coulissant)

Mentioned in Radio! Radio! (p.192, fig.750.)
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1100)
Literature/Schematics (2) Radio And Television Servicing books (R&TVS) (1957 (7 vol ed) Vol1, not 1952 Ed Vol1)

Model page created by Jean Claude Pigeon † 2008. See "Data change" for further contributors.



All listed radios etc. from Ultra Electric Ltd.; London
Here you find 218 models, 129 with images and 149 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Ultra Electric Ltd.;: Coronation Twin Deluxe R906
Threads: 2 | Posts: 5
Hits: 1750     Replies: 2
ultra: Ultra Twin Models
Michael Watterson
08.Mar.14
  1

As I write we know of the following nine Ultra Twin Models.

These are all covered by one Trader (963) and R&TVS (1952 & 1957 editions Vol 1) entry:

  • Ultra Twin 50 R656 or Carnival Twin  (Separate 85.5V & 7.5V HT & LT batteries) Trader 963. A revised version of R586 with different case style.
  • Ultra Twin R568 (Trader Recommend 963 as "Similar)  R&TVS "Twin" is R568 or R656
  • Ultra Twin R586  Or Twin 50 (Single combo 85.5V & 7.5V B127 Battery pack, B127)  R&TVS 1952 calls this a Twin 50. Different style case to the rest, like mains R589 The Trader 963 refers to this as the earlier model
  • Ultra Carnival Twin R746 (Trader Recommend 963 as "Similar) R&TVS "Carnival Twin"

If two plugs for  batteries: HT 85V = Ever Ready B129, LT 7.5V = Ever Ready AD39

If single plug for batteries: Ever Ready B127 85V + 7.5V combo pack

Separately but still similar

Coronation Twin Deluxe R906 Offenbach 53 (leather)
  • Ultra Twin R825 Last twin and  using low consumption valves (Nominal 25mA rather than 50mA series)

VHF-FM Offenback Models vs AM only Ultra Twin.

While Germany had VHF-FM from 1949 and a variety of Stations not on AM due to Russian and Allied use of frequencies, the UK only had VHF-FM from 1955 with a very slow "rollout" starting in South East (to combat interference on MW BBC Third) and only simulcast of BBC Home, Light and Third till 1970s, with poor signal strength in 1950s, so no UK VHF-FM battery portable models other than 1957 Vidor "Vanguard" and 1958 Ever Ready "Sky Emperor" (BEREC "Commander"). There was only one 1955 Battery valve Table model (USA call them Farm Radios) the Ever Ready "Sky Monarch AM/FM". Ultra never made any Battery Valve VHF models. Ultra became part of Thorn  (BRC / Ferguson) and no more than a label by 1960s.

Why Twin?

They are called "Twin" because of dual mains or battery operation. Some have a captive mains lead that is internally docked to switch to battery, others use a two pin plug with battery mains switch on chassis and removable mains lead with inline socket. As some models are very similar cabinet and the knob on wavechange switch can be lost exact identification can be difficult if the paper label on rear panel is missing. The slats on rear panel break easily. Loop aerial on rear. Some versions have an aerial socket. All are potentially live chassis on mains operation.

Ultra don't seem to be consistent on exact model name (Twin, Twin50, Carnival Twin) in adverts.

While the rear and main case appear to be Bakelite (except Coronation Twin Deluxe R906) the pale fromt panel may be some other material,

A similar styled mains only model is the R5897 (very similar to Twin R586 and Export Twin WR5897), the Troubadour U626 is more different but similar materials.

These models taking into account inflation and comparing wages would have cost more than an HDTV today and between one and two weeks wages in early 1950s.

Howard Craven
10.Mar.14
  2

Hello Michael,

I have several of these nice little sets and also the two Twin DeLuxe models. Just one thing regarding the R906 DeLuxe models, in the Ultra Service manual this is referred to as the Ultra Twin De Luxe without 'Coronation'. The manual is also dated July 1955 suggesting that it was not built in the year of the coronation 1953.

Regards ......... Howard





Michael Watterson
10.Mar.14
  3

Possibly the Deluxe wasn't advertised as a "Coronation Twin Deluxe", But Makers Service Manual issue dates are not reliable.

This advert looks identical to the Cornation Twin, R786.







Actual Coronation Twin Advert:



I think it's probable the R906 is officially the "Ultra Twin Deluxe" (without Coronation), but it's a unique case for Ultra and undoubtably virtually the Coronation Twin R786 chassis, so I don't think the description is particularly harmfull. Hopefully people will read our articles and see that we can't be 100% dogmatic except for Model numbers of an example with original back and label! As you know that's why the photo of a Model Label is very desirable from Members, Guests or Auction photos.

But look at the photos uploaded for the Ultra Twin R766, there are two kinds of front panel there, one matches the advert above and the Coronation Twin R786 case. Also the Ultra Twin R568  vs Ultra Twin R586  apparently the earlier version?

Adverts frequently don't have model numbers and the paper labels are frequently missing. The R&TVS only has a chassis drawing if you are lucky and Trader sheets may only illustrate one of several identical or similar chassis on one issue.

You can't even 100% go by a distinctive case! The very last models of Ever Ready T (four versions) use 25mA Dx96 series and early Sky Queen is identical. There are both mechanical and electrical revsions of the original Sky Queen.  I just got some photos from South Africa and the earlier Saucepan (Serial J 307879 has rectangular  IFTs (not square like A, C, C/A or C/E) with 4 round rear vents on case  and later (Serial J 346853) it has round IFTs (Like K, T & Sky Queen etc)  and front + side is two part, not single part like a saucepan base and no vents in rear.

So I think you are correct there are nine Ultra Twin and we have the corrent Model Numbers, you are probably correct on name of the Deluxe Twin R906 but some of the other models are more dubious in name and they are all very similar electrically and related chassis.




Hits: 1768     Replies: 1
ultra: R906 Coronation twin / Coronation Twin DeLuxe differences?
Wolfgang Scheida
14.Sep.10
  1

Is there really a difference between Ultra Coronation Twin DeLuxe & Ultra Coronation Twin known?



Model tube quantity shows 5 but uploaded schematic only shows 4 tubes!

For my part, the suffix "Deluxe" indicates the special cabinet covering only ?

Thanks for help!

Howard Craven
14.Sep.10
  2



Hello Wolfgang,

There is a model page for the Ultra Coronation Twin, model R786, released in April 1953,  the year of the coronation of Queen Elizabeth II  ....

Ultra R786 Coronation Twin

And there is a model page for the Ultra Twin De luxe, model R906 released in July 1955 ...

Ultra R906 Twin De Luxe

A picture of the De Luxe R906 model appears in Jonathan Hill's book Radio! Radio! as a "Coronation Twin" but as far as I am aware it was never given that title by Ultra, in the manufacturer's 1955 first edition service manual it was simply called the Twin De Luxe. I have pointed out this error before so a note has been added to the R906 model page stating 'It is not clear whether J.Hill refers to the model number R786 only or to its name "Coronation Twin".

Both models have 4 valves and their circuitry is similar, but as can been seen the casework is totally different.

So the model page in question is a duplicate of the R906 page above, it should be closed and the picture on it moved.

Regards ........... Howard






















Ultra Electric Ltd.;: Coronation Twin Deluxe R906
End of forum contributions about this model
