- Country
- Italy
- Manufacturer / Brand
- Vega, BP Radio, Brionvega, Brion & Pajetta; Milano, Lissone (MI)
- Year
- 1955/1956
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 118640
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: FM101 - Vega, BP Radio, Brionvega,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 400 x 240 x 180 mm / 15.7 x 9.4 x 7.1 inch
- Source of data
- Guida Pratica Antique Radio (1) 1999
- Literature/Schematics (1)
- -- Schematic (D.E. Ravalico, Il Radiolibro, 16° edizione, 1957, Hoepli)
- Author
- Model page created by Alessandro De Poi. See "Data change" for further contributors.
