Benczur T4302 OIRT

Benczur T4302; Videoton; (ID = 593820) Television Benczur T4302; Videoton; (ID = 644677) Television
Benczur T4302; Videoton; (ID = 644676) Television Benczur T4302; Videoton; (ID = 644678) Television
Benczur T4302; Videoton; (ID = 644679) Television Benczur T4302; Videoton; (ID = 644680) Television
Use red slider bar for more.
Benczur T4302; Videoton; (ID = 593820) Television
Videoton;: Benczur T4302 [Television] ID = 593820 600x488
Select picture or schematic to display from thumbnails on the right and click for download.
For model Benczur T4302 OIRT, Videoton; Székesfehérvár:
Thanks for Mr.Herczeg István Veszprém, Hungary!

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1960/1961 Category: Television Receiver (TV) or Monitor
Valves / Tubes 19: PCC88 PCF82 EF80 EF80 EF80 PCL84 ECH81 EF80 PABC80 PL82 ECH81 ECH81 PCL82 PL36 PY83 EY86 AW43-80
Main principle Superheterodyne (common)
Wave bands Ready for FM, has Broadcast, Long Wave, Short wave.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Benczur T4302 [OIRT] - Videoton; Székesfehérvár
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 405 x 510 x 450 mm / 15.9 x 20.1 x 17.7 inch
Notes OIRT Kanal 1-12, 5 Dioden, 2 Ovallautsprecher. Screen: 43 cm.
Net weight (2.2 lb = 1 kg) 27 kg / 59 lb 7.5 oz (59.471 lb)
Price in first year of sale 5'400.00 HUF
Source of data Radio es Televizio Vevö Keszülekek, 1960-63
Literature/Schematics (4) Villamossági tömegcikkek árjegyzéke, Bp. 1961

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
