Carmen TA-631 (RA-631)

Videoton; Székesfehérvár

Data

Forum

Pictures

Collections

Country
Hungary

Manufacturer / Brand
Videoton; Székesfehérvár

Year
1960 ?

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
151474

- Brand: VTTV

Schematics

Carmen TA-631 ; Videoton; (ID = 593831) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1196280) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1196284) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1196286) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1196287) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1668844) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1668845) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1668846) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1668847) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1965693) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1965694) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1965695) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1965696) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1965697) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 1965698) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 2083175) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 2083176) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 2083177) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 2083178) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 2083179) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 2083180) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 2083181) Television — Videoton; Carmen TA-631 (2)

Carmen TA-631 ; Videoton; (ID = 2083182) Television — Videoton; Carmen TA-631 (2)

Technical Specifications

Number of Tubes
15

Valves / Tubes
EC92 PCF82 EF80 PCL84 EF80 PABC80 PL82 PCF82 ECH81 PCL82 PL36 PY83 EY83 AW43-80

Main principle
Superheterodyne (common)

Wave bands
Wave Bands given in the notes.

Power type and voltage
Alternating Current supply (AC) / 220 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

Power out
1.2 W (unknown quality)

Material
Wooden case

from Radiomuseum.org
Model: Carmen TA-631 - Videoton; Székesfehérvár

Shape
Tablemodel, with any shape - general.

Dimensions (WHD)
360 x 450 x 400 mm / 14.2 x 17.7 x 15.7 inch

Notes
RA-631 is a misspelling used in Kádár book.
OIRT channel 1 - 12.

Net weight (2.2 lb = 1 kg)
26 kg / 57 lb 4.3 oz (57.269 lb)

Price in first year of sale
4,200.00 HUF

Source of data
Radio es Televizio Vevö Keszülekek, 1960-63

Author
Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
