Kékes TB-43

Kékes TB-43; Videoton; (ID = 717397) Television Kékes TB-43; Videoton; (ID = 717398) Television
Kékes TB-43; Videoton; (ID = 717401) Television Kékes TB-43; Videoton; (ID = 717403) Television
Kékes TB-43; Videoton; (ID = 717404) Television Kékes TB-43; Videoton; (ID = 717405) Television
Kékes TB-43; Videoton; (ID = 717530) Television Kékes TB-43; Videoton; (ID = 717531) Television
Kékes TB-43; Videoton; (ID = 1627337) Television Kékes TB-43; Videoton; (ID = 2081250) Television
Use red slider bar for more.
Kékes TB-43; Videoton; (ID = 717397) Television
Videoton;: Kékes TB-43 [Television] ID = 717397 670x532
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kékes TB-43, Videoton; Székesfehérvár:
Thanks for Mr. Tasnádi Zsolt, Hungary!

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1961–1964 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 19: PCC88 PCF82 EF80 EF80 EF80 PCL84 ECH81 EF80 EF80 PABC80 PL82 ECH81 PCL82 PL36 PY83 EY86 PY82 PY82 AW43-80
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: Kékes TB-43 - Videoton; Székesfehérvár
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 405 x 510 x 450 mm / 15.9 x 20.1 x 17.7 inch
Notes Bild tube 43 cm, OIRT 1-12, 5 dioden.
Net weight (2.2 lb = 1 kg) 30 kg / 66 lb 1.3 oz (66.079 lb)
Price in first year of sale 5'200.00 Forint
Source of data Radio es Televizio Vevö Keszülekek, 1960-63
Mentioned in -- Original prospect or advert

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
