Zephyrette 764

Zephyrette 764; Voxson F.A.R.E.T., (ID = 1367473) Radio
Zephyrette 764; Voxson F.A.R.E.T., (ID = 2433877) Radio Zephyrette 764; Voxson F.A.R.E.T., (ID = 2433878) Radio
Zephyrette 764; Voxson F.A.R.E.T., (ID = 2433880) Radio Zephyrette 764; Voxson F.A.R.E.T., (ID = 2433879) Radio
Zephyrette 764; Voxson F.A.R.E.T., (ID = 568918) Radio Zephyrette 764; Voxson F.A.R.E.T., (ID = 568919) Radio
Zephyrette 764; Voxson F.A.R.E.T., (ID = 1161881) Radio Zephyrette 764; Voxson F.A.R.E.T., (ID = 1367463) Radio
Use red slider bar for more.
Zephyrette 764; Voxson F.A.R.E.T., (ID = 2433877) Radio
Voxson F.A.R.E.T.,: Zephyrette 764 [Radio] ID = 2433877 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Zephyrette 764, Voxson F.A.R.E.T., Roma

Country:  Italy
Manufacturer / Brand:  Voxson F.A.R.E.T., Roma
Year: 1963 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: SFT308 SFT307 SFT307 SFT353 SFT323 SFT323
Main principle Superheterodyne (common); 2 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 6x1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Zephyrette 764 - Voxson F.A.R.E.T., Roma
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 166 x 97 x 40 mm / 6.5 x 3.8 x 1.6 inch
Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)
Price in first year of sale 13'000.00 ITL
Mentioned in Catalogo ANIE 1965-66
Literature/Schematics (1) Antique Radio Magazine n.67, June-July 2005, page 10. Written in Italian.

Model page created by Aldo Andreani. See "Data change" for further contributors.
