NF-Telefonrundspruch 38

NF-Telefonrundspruch 38; Zellweger AG; Uster (ID = 20838) Wired-W
Use red slider bar for more.
NF-Telefonrundspruch 38; Zellweger AG; Uster (ID = 20838) Wired-W
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Switzerland
Manufacturer / Brand:  Zellweger AG; Uster
Year: 1938 ? Category: Wired Receiver (AF only)
Valves / Tubes 3: AC2 AD1 AZ1
Main principle Audio-Amplification; 2 AF stage(s)
Wave bands - without
Details Wired Wireless Receiver(AF only)
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 220 Volt
Loudspeaker Presumably Dynamic Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: NF-Telefonrundspruch 38 - Zellweger AG; Uster
Notes NF-Telefonrundspruch
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
