BF245B

Information - Help
ID = 37068

Country:
Germany
Brand: Valvo GmbH, Radioröhrenfabrik; Hamburg
Tube type:  Transistor   Universal
Identical to BF245B
Similar Tubes
Normally replaceable-slightly different:
  2N3819 ; 2N3823 ; 2N5458 ; 2SK118 ; BC264 ; BF244 ; BF245 ; BF247 ; BF256 ; MPF102
Different maximum ratings:
  2SK55
First Source (s)
Mar.1968 : -- Collector info (Sammler)

Base Wires
Filament Solid State
Description Material/Aufbau: Silizium N-Kanal-Sperrschicht-FET;
Form/Case: TO-92 / TO-54 / R-110 (Anschlussfolge: DSG);
Daten/electr.data: I F: 10 mA; U F: 30 V; ß (beta): 5.5; N: 360 mW; Imax: 7-11 mA; Umax: 30 V; f g (FT): __ MHz; tmax j: (150) °C;
More Information: see BF245.
Dimensions (WHD)
incl. pins / tip
6 x 6 x 5 mm / 0.24 x 0.24 x 0.20 inch
Weight 1 g / 0.04 oz
Information source -- Collector info (Sammler)   KTT 1969/70
  BF245B: Funktechnik 4/68
Egon Strampe

BF245B: Sammlung
Karlheinz Fischer


BF245B: TVT 1969 Verlag Nolde Dachau
Günther Stabe † 19.8.20


BF245B: Siemens Transistoren 1980/81
Oskar Elm


Usage in Models 1= 1970? ; 2= 1976 ; 1= 1977 ; 1= 1979 ; 1= 1985??

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):6
