BRY39

Information - Help
ID = 37069

Country:
Germany
Brand: Valvo GmbH, Radioröhrenfabrik; Hamburg
Tube type:  Thyristor
Identical to BRY39
Similar Tubes
Normally replaceable-slightly different:
  ON328
First Source (s)
Feb.1968 : - - Manufacturers Literature

Base Wires
Filament Solid State
Description

Material/Aufbau: Silizium Planar Thyristor-Tetrode PNPN;
PUT = Programmable Unijunction Transistor;
Form/Case/Outline: TO-72 Anschlussfolge K-Gk-Ga-A;
Daten/electr.data: Uga k r | Uga A O: max 70 V; Ia AV: <175 mA; Ia M: <2.5 A; Ptot: 275 mW; tmax j: 150 °C;
Anwendung/Application: Steuerung von Ziffern- u. Zeichen-Anzeigeröhren;
Varianten: BRY39-Ox / BRY39-P / BRY39-S / BRY39-T / ...,
-


Dimensions (WHD)
incl. pins / tip
6 x 6 x 6 mm / 0.24 x 0.24 x 0.24 inch
Weight 1 g / 0.04 oz
Information source -- Collector info (Sammler)   Valvo Handbuch 1968, Datenbuch 1984
  BRY39: Valvo Datenbuch 1984
Günther Stabe † 19.8.20

BRY39: Sammlung
Karlheinz Fischer

More ...

BRY39: Valvo Handbuch 1968
Günther Stabe † 19.8.20


BRY39: Valvo Datenbuch 1984
Günther Stabe † 19.8.20

More ...

Usage in Models 1= 1982

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):1
