TDA7021T

Information - Help
ID = 46108

Country:
Netherlands
Brand: Philips; Eindhoven (tubes international!); Miniwatt
Tube type:  IC - Integrated Circuit   VHF
Identical to TDA7021T

Base Wires
Filament Solid State
Description

Monolithic integrated circuit: FM single chip radio (without AF power amplifier); low IF (76 kHz), mono / stereo, 3 V, 6.3 mA, LFF, MTS (micro tuning system) .
-


Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
10 x 2 x 4 mm / 0.39 x 0.08 x 0.16 inch
Weight 1 g / 0.04 oz
Information source - - Manufacturers Literature   Philips
  TDA7021T: Philips
Günther Stabe

TDA7021T: G.S.
Günther Stabe


TDA7021T: Philips
Günther Stabe


TDA7021T: Philips
Günther Stabe


Usage in Models 1= 1985?? ; 1= 1987 ; 1= 1988? ; 1= 1989? ; 1= 1990?? ; 1= 1994?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):6
