Quad 77 CD Player 7712

Quad (Brand); Acoustical Manufacturing Co. Ltd.; Huntingdon

Data
Forum
Pictures
Collections

  • Year
  • 1996 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 317692

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 110-120; 220-240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Quad 77 CD Player 7712 - Quad Brand; Acoustical
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 321 x 60 x 300 mm / 12.6 x 2.4 x 11.8 inch
  • Notes

  • A stereo hi-fi compact disc player in a nextel or carbon finish cabinet in the Quad 77 Series of hi-fi separates. Remote control operation is provided by the Quad 77 System Console when the player is connected to the Quadlink bus, alternatively a Quad 77 remote control is available separately for this model. With RCA phono Line Output sockets and two "Quadlink" connectors for connection to the 77 Integrated Amplifier or 77 Preamplifier and to other Quad 77 separates.

    See also the Quad 77 Compact Disc Player type 7714 with identical performance which is powered via the Quadlink Bus and has no Line Out phono sockets, so can only be used in a Quad 77 system.

    Specification
    Operation: Full function by QUAD two way infrared remote
    control or basic operation without remote control.
    Frequency response: <±0.1dB 20-20,000Hz.
    Phase linearity: <±0.5° 20-20,000Hz.
    Signal/noise ratio: >100dB 20-20,000Hz.
    Crosstalk: <100dB at 1kHz.
    Total harmonic distortion: <0.002% at 1kHz.
    Wow and flutter: Below measurement levels.
    D/A conversion: 18 bit 64 x oversampling. Delta - Sigma converter.
    Audio output: 2V rms max. Minimum load impedance 10kΩ.

    Power requirements
    110-120V or 220-240V AC 50-60Hz.

    Power consumption:  14W approx.

  • Net weight (2.2 lb = 1 kg)
  • 3.5 kg / 7 lb 11.3 oz (7.709 lb)
  • Price in first year of sale
  • 850.00 £
  • Mentioned in
  • Gramophone magazine Nov 1995 Quad 77 CD review
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Quad 77 Compact Disc Player Instruction Book)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
