Bimby 59

ID = 21629

Bimby 59; AEG Radios Allg. (ID = 1268788) Radio

Bimby 59; AEG Radios Allg. (ID = 1268660) Radio

Bimby 59; AEG Radios Allg. (ID = 1268661) Radio

Bimby 59; AEG Radios Allg. (ID = 1959088) Radio

Bimby 59; AEG Radios Allg. (ID = 1959089) Radio

Bimby 59; AEG Radios Allg. (ID = 1959090) Radio

Bimby 59; AEG Radios Allg. (ID = 1959091) Radio

{gbW: "1400", gbH: "888", mW: "500", mH: "317.0", kb: "255 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.:[br]AEG Bimby 59 - vorne", title: "AEG Radios Allg. Bimby 59 from Frank Winter (1)", ite: "1"} {gbW: "1400", gbH: "859", mW: "500", mH: "306.0", kb: "236 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.:[br]AEG Bimby 59 - hinten offen", title: "AEG Radios Allg. Bimby 59 from Frank Winter (1)", ite: "1"} {gbW: "1400", gbH: "913", mW: "500", mH: "326.0", kb: "207 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.:[br]AEG Bimby 59 - hinten", title: "AEG Radios Allg. Bimby 59 from Frank Winter (1)", ite: "1"} {gbW: "1400", gbH: "788", mW: "500", mH: "281.0", kb: "188 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.:[br]AEG Bimby 59 - hinten detail Schrift", title: "AEG Radios Allg. Bimby 59 from Frank Winter (1)", ite: "1"} {gbW: "1400", gbH: "788", mW: "500", mH: "281.0", kb: "180 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.:[br]AEG Bimby 59 - hinten detail röhren", title: "AEG Radios Allg. Bimby 59 from Frank Winter (1)", ite: "1"} {gbW: "1400", gbH: "788", mW: "500", mH: "281.0", kb: "235 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.:[br]AEG Bimby 59 - vorne Detail", title: "AEG Radios Allg. Bimby 59 from Frank Winter (1)", ite: "1"} {gbW: "1388", gbH: "1129", mW: "461.0", mH: "375", kb: "141 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Bimby 59 from Manuel Pardo-Santiago (1)", ite: "1"} {gbW: "1400", gbH: "946", mW: "500", mH: "337.0", kb: "172 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Bimby 59 from Manuel Pardo-Santiago (1)", ite: "1"} {gbW: "1400", gbH: "958", mW: "500", mH: "342.0", kb: "119 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Bimby 59 from Manuel Pardo-Santiago (1)", ite: "1"} {gbW: "1400", gbH: "931", mW: "500", mH: "332.0", kb: "190 KB", notes: "For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.:[br]AEG Bimby59_Hauptansicht", title: "AEG Radios Allg. Bimby 59 from Peter Breu (1)", ite: "1"}

Bimby 59; AEG Radios Allg. (ID = 2387390) Radio

Bimby 59; AEG Radios Allg. (ID = 1848912) Radio

Bimby 59; AEG Radios Allg. (ID = 1848915) Radio

Bimby 59; AEG Radios Allg. (ID = 1848913) Radio

Bimby 59; AEG Radios Allg. (ID = 2373516) Radio

Next pictures

Use red slider bar for more.

Bimby 59; AEG Radios Allg. (ID = 2387389) Radio

AEG Radios Allg.: Bimby 59 [Radio] ID = 2387389 1400x888

Select picture or schematic to display from thumbnails on the right and click for download.

For model Bimby 59, AEG (Radios) Allg.Elektricitäts-Ges.:
AEG Bimby 59 - vorne

Country:

Germany

Manufacturer / Brand:

AEG (Radios) Allg.Elektricitäts-Ges.

Year: 1958/1959

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

6: ECC85 ECH81 EF89 EABC80 EM80 EL84

Main principle	Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits	6 AM circuit(s) 10 FM circuit(s)
Wave bands	Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage	Alternating Current supply (AC) / 110-240 Volt
Loudspeaker	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out	2.5 W (undistorted)
from Radiomuseum.org	Model: Bimby 59 - AEG Radios Allg.Elektricitäts-
Material	Wooden case
Shape	Tablemodel with Push Buttons.
Dimensions (WHD)	345 x 230 x 200 mm / 13.6 x 9.1 x 7.9 inch
Net weight (2.2 lb = 1 kg)	5.5 kg / 12 lb 1.8 oz (12.115 lb)
Price in first year of sale	229.00 DM
External source of data	Erb
Source of data	HdB d.Rdf-& Ferns-GrH 1958/59
