For model 1029, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: EC92 EC92 ECH81 EF85 EM80 EABC80 ECC83 EL84 EL84
Main principle Superheterodyne (common); ZF/IF 485/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker 5 Loudspeakers
Power out
from Radiomuseum.org Model: 1029 - Asa, Turku
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 590 x 390 x 270 mm / 23.2 x 15.4 x 10.6 inch
Notes Rectifier: B250C100
Price in first year of sale 47'700.00 FIM

Model page created by Timo Rantasaari. See "Data change" for further contributors.
