6W78

6W78; Blaupunkt Ideal, (ID = 27073) Radio

6W78; Blaupunkt Ideal, (ID = 6621) Radio

6W78; Blaupunkt Ideal, (ID = 337617) Radio

6W78; Blaupunkt Ideal, (ID = 27074) Radio

6W78; Blaupunkt Ideal, (ID = 1524358) Radio

6W78; Blaupunkt Ideal, (ID = 2245958) Radio

6W78; Blaupunkt Ideal, (ID = 2245959) Radio

6W78; Blaupunkt Ideal, (ID = 2245960) Radio

6W78; Blaupunkt Ideal, (ID = 2245961) Radio

6W78; Blaupunkt Ideal, (ID = 2245962) Radio
6W78; Blaupunkt Ideal, (ID = 253325) Radio 6W78; Blaupunkt Ideal, (ID = 31537) Radio
6W78; Blaupunkt Ideal, (ID = 31538) Radio 6W78; Blaupunkt Ideal, (ID = 707766) Radio
6W78; Blaupunkt Ideal, (ID = 31472) Radio 6W78; Blaupunkt Ideal, (ID = 31539) Radio
6W78; Blaupunkt Ideal, (ID = 3298) Radio 6W78; Blaupunkt Ideal, (ID = 276350) Radio
6W78; Blaupunkt Ideal, (ID = 276351) Radio 6W78; Blaupunkt Ideal, (ID = 276352) Radio
Use red slider bar for more.
6W78; Blaupunkt Ideal, (ID = 253325) Radio
Blaupunkt Ideal,: 6W78 [Radio] ID = 253325 893x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model 6W78, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ACH1 AF3 AB2 AL4 EFM11 AZ1
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 6W78 - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 538 x 392 x 292 mm / 21.2 x 15.4 x 11.5 inch
Notes variable Bandbreite
Net weight (2.2 lb = 1 kg) 18 kg / 39 lb 10.4 oz (39.648 lb)
Price in first year of sale 263.00 RM
Collectors' prices
Source of data Handbuch WDRG 1938 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
