Sevilla US 7653

Blaupunkt (Ideal), Berlin, später Hildesheim

Data
Forum
Pictures
Collections

  • Year
  • 1959/1960
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 332207
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

 Technical Specifications

  • Number of Tubes
  • 19
  • Number of Transistors
  • Main principle
  • Superhet with RF-stage; Export model
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60 Hz, 110-120; 220-240 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Sevilla US 7653 - Blaupunkt Ideal, Berlin,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 22 x 21 x 16 inch / 559 x 533 x 406 mm
  • Notes

  • Blaupunkt Sevilla US 7653 is an export model for the USA.
    Bands: 12 channels (A2-A13), US Standard of 525 lines

    See also the German domestic model Sevilla 7650

  • Net weight (2.2 lb = 1 kg)
  • 68 lb (68 lb 0 oz) / 30.872 kg
  • Mentioned in
  • -- Original prospect or advert (Blaupunkt Prospekt 1959/60)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Blaupunkt Technisches Rundschreiben FE1/63)
  • Author
  • Model page created by Richard Winter. See "Data change" for further contributors.
