- Country
- Italy
- Manufacturer / Brand
- CGE, Compagnia Generale di Elettricità; Milano
- Year
- 1966 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 342508
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 20
- Valves / Tubes
- ECC189 ECF86 EC88 EC86 EF183 EF80 EF80 ECF82 ECL84 ECH81 EF80 EABC80 EL84 EAA91 ECC82 ECL82 EL500 EY83 DY86 19CWP4
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 120-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: TX234 - CGE, Compagnia Generale di
- Notes
-
Televisore in bianco/nero con VHF e UHF. Cinescopio con deflessione 110°.
I modelli da 19 pollici erano equipaggiati, oltre che con il cinescopio 19CWP4 anche con il 19AMP4. I modelli da 23 pollici erano equipaggiati con i cinescopi A59-16W e 23BP4.
- Mentioned in
- -- Schematic (“Televisori Commerciali” E. Costa U. Hoepli editore, 1966.)
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
