Concerton AB 1517

• Country
• Sweden

• Manufacturer / Brand
• Stern & Stern (Concerton / Conserton), S&S; Stockholm

• Year
• 1957 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 219225

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• DC90 DF96 DF96 DK96 DF96 DAF96 DL94

• Main principle
• Superheterodyne (common); ZF/IF 468/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 110; 125; 145; 220 / 1,5 & 90 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Concerton AB 1517 - Stern & Stern Concerton /

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 350 x 250 x 115 mm / 13.8 x 9.8 x 4.5 inch

• Notes
• Model AB 1517 is similar to Concerton AB 1519,
  Philips LS462AB and Philips L4S72AB.

• Net weight (2.2 lb = 1 kg)
• 4.3 kg / 9 lb 7.5 oz (9.471 lb)
