For model V1385, Dux Radio AB; Stockholm:
Courtesy .skanesauktionsverk.se

Country:  Sweden
Manufacturer / Brand:  Dux Radio AB; Stockholm
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM80 EL84
Main principle Super-Heterodyne (Super in general); ZF/IF 468/10850 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: V1385 - Dux Radio AB; Stockholm
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes According to the plans from June 1958 the Dux Type V1385 uses the same chassis like Conserton V518 and V5048 and Philips BS371A, B4S71A, H4S73A.

Model page created by Ernst Erb. See "Data change" for further contributors.
