64/48W

64/48W; EAK, Elektro- (ID = 17570) Radio
64/48W; EAK, Elektro- (ID = 2364588) Radio 64/48W; EAK, Elektro- (ID = 2364589) Radio
64/48W; EAK, Elektro- (ID = 2376733) Radio
Use red slider bar for more.
64/48W; EAK, Elektro- (ID = 2364588) Radio
EAK, Elektro-: 64/48W [Radio] ID = 2364588 1400x983
Select picture or schematic to display from thumbnails on the right and click for download.
For model 64/48W, EAK, Elektro-Apparatefabrik Köppelsdorf, ex AEG (Sonneberg):
Auffindezustand

Country:  Germany
Manufacturer / Brand:  EAK, Elektro-Apparatefabrik Köppelsdorf, ex AEG (Sonneberg)
Year: 1948/1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH11 EBF11 ECL11 AZ11 or AZ1
Main principle Superheterodyne (common); ZF/IF 468 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 64/48W - EAK, Elektro-Apparatefabrik
Collectors' prices
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange-Nowisch
